250L/H RO SYSTEM 2000 GPD
Description
This compact commercial reverse osmosis system is a durable piece of equipment which, with proper care and maintenance will last for many years. RD series systems are part of a family of reverse osmosis units designed for operation with fresh and brackish feed waters having TDS values below 2,000ppm. Models are available with permeate outputs ofbetween 300 and 700 litresfhr as shown in the specifications tables.
Specifications
- Capacity (GDP/LPH): 2000/300
- Working Pressure (PSI/BAR): 150-200/10-14
- Pre-Filtration: (20″ Filter Housing x2) + (20″ PP Cartridge 5u + 1u)
- Booster Pump: Rotary Van Pump Motor (1HP)
- Membrane Material: T.F.C with FRP outer wrap Size + Unit: 4040 x 1
- Membrane Housing Material: High Pressure TRP end port type Size x Unit: 4040 x 1
- Flow Meters: Permeate/Concentrate
- Pressure Gauges: Feed water pressure/Booster pump outlet pressure gauge
- Water Quality Indicator: T.D.S meter with LCD
- Electrical Controls: Micro-computer control, overload breakers, LED indicators
- Frame: Electro-polished stainless steel 304
- Weight: 64KG Feed Water Parameters
- Turbity (SD): <5
- T.D.S.: <2000 ppm=”” br=””>Temperature: +5 to 40 oC
- Free Chlorine: 0 ppm
- pH: 3-11 Iron: <0.01 ppm=”” p=””>
- Iron: <0.01 ppm=”” p=””>
